ORIGINAL FEED SECTION
6-11
SM C231/C237/C238
Replacement
and
Adjustment
6.4 ORIGINAL FEED SECTION
6.4.1 ADF ROLLER ASSSEMBLY
A: ADF Roller Assembly
6.4.2 PICK-UP ROLLER
A: Pick-up Roller (2 clips, 2 gears)
C231P507.WMF
C231P508.WMF
[A]
[A]
