1.5 ELECTRICAL COMPONENT LAYOUT
1.5.1 ADF
Motors
Index No. Name Function
4 ADF Motor Drives the original.
Switches
Index No. Name Function
3 ADF Cover Switch Detects whether the ADF cover is open or
closed.
5 ADF Switch Detects whether the ADF unit is open or closed.
Sensors
Index No. Name Function
2 Scan Line Sensor Detects when a page is approaching the auto
shading position.
1 Document Sensor Detects the presence of a document in the
feeder.
6 Not Used
C231V508.WMF
1
2
3
4
5
6
