Ricoh C231 - Registration Roller

PRINTING
C267 3-38 SM
3.8.6 REGISTRATION ROLLER
z Front cover ( 3.2.1)
z Rear cover ( 3.2.3)
[A]: Paper table ( x 1,  x 2)
[B]: Plate ( x 4)
z MPU ( 3.3.1)
z PSU ( 3.3.2)
z Registration motor ( 3.8.5)
C267R029.WMF
C267R030.WMF
[A]
[B]
