PRINTING
SM 3-39 C267
C267 Service
Manual
[C]: Gear
[D]: Bearing ( x 2)
[E]: Registration roller
NOTE:
The flange of gear [C] should face towards the machine, as shown in the
diagram.
C267R028.WMF
C267R031.WMF
[E]
[D]
0±0.5 mm
[C]
