SERVICE PROGRAM TABLE
4-20
C231/C237/C238 SM
Remarks
1. SP Mode No. 31 and 37 - SCN/ADF Center Adjust
The printing position moves as shown below.
←
Direction
Original Position
+X: Moves up X mm
Printing Position
-X: Moves down X mm
Printing Position
NOTE:
When adjusting the scanner image position, input "0" first:
Example) X = 0.9 mm
→
"0", "9", then press the # key.
X mm
