SERVICE PROGRAM TABLE
4-21
SM C231/C237/C238
Service
Tables
2. SP Mode No. 38 - ADF Scan Line Adjust
The printing position moves as shown below.
←
Direction
Original Position
+X: Moves X mm to the left
Printing Position
-X: Moves X mm to the right
Printing Position
3. SP Mode No. 52 - Compress With Start Key, SP Mode No. 85 - Initial
Compression
These modes eliminate the possible causes of master eject jams. If the operator
continues to make masters even after the master eject box becomes full, the
ejected masters will interfere with the movement of the pressure plate, causing
another master eject jam.
When these modes are selected, the full master box detection, with the master
compressing operation, is carried out each time the machine is switched on (SP85)
or the Start key is pressed to make a new master (SP52). Selecting SP52 affects
the master processing time, so this is not enabled as the default. SP85 is enabled
as the default.
X mm
