INPUT/OUTPUT CHECK MODE
4-25
SM C231/C237/C238
Service
Tables
Code LCD Display Component Checked
53
SN: Cutter
Home Position
In-53
Cutter Home Position Sensor
54 SN: Master Set Cover
In-54
Master Set Cover Sensor
56
SN: Feed Start
Timing
In-56
Feed Start Timing Sensor
57
SN: 2nd Feed
Timing
In-57
2nd Feed Timing Sensor
58
SN: Paper Exit
Timing
In-58
Paper Exit Timing Sensor
59 SN: Master Eject
Position
In-59
Master Eject Position Sensor
62 SN: Drum Set
In-62
When the drum connector is connected
65 SN: Clamper Close
In-65
Clamper Close Sensor
66 SN: Clamper Open
In-66
Clamper Open Sensor
68 SN: Registration
In-68
Paper Registration Sensor
