INSTALLATION PROCEDURE
SM 1-9 C231/C237/C238
Installation
1.2.2 PLATEN COVER INSTALLATION (OPTION)
Accessory Check
Check the quantity and condition of the accessories in the box against the following
list:
Description Quantity
1. Stepped Screw.............................................................................. 2
Installation Procedure
1. Install the platen cover [A] (2 screws).
C238I001.WMF
[A]
