INSTALLATION PROCEDURE
C231/C237/C238 1-20 SM
- For C217 and C225 -
1. Turn off the main switch and unplug the power cord.
2. Install the tape marker on the main body with two knob screws [A]
(accessories) in the two inner holes of the tape marker bracket.
NOTE: 1) Tighten the knob screws with a screwdriver to prevent them from
coming loose.
2) Install the lock washer [B] (accessory) with the lower of the two knob
screws.
3. Refer to “Common Steps”.
C238I503.PCX
[A]
[B]
To Next Page
