DRUM
C231/C237/C238 3-26 SM
3.8.5 INK ROLLER UNIT / INK ROLLER ONE-WAY CLUTCH
•
Metal screen (

3.8.3)
•
Pump covers (

3.8.4)
[A]: Board cover (

x 2)
[B]: Front stay (

x 2,

x 3)
[C]: Front flange
[D]: Rear stay (

x 2)
[E]: Rear stoppers (

x 1)
[F]: Ring
[G]: Rear flange
[H]: Ink roller unit
[I]: Ink roller one-way clutch
C238R023.WMF
C238R060.WMF
C238R033.WMF
[D]
[E]
[F]
[G]
[E]
[I]
[H]
[A]
[B]
[C]
