TIMING CHART
C231/C237/C238 6-40 SM
6.9.2 MASTER WRAPPING
Wrapping the master
Master eject position SN
Feed start timing SN
2nd feed timing SN
Paper exit timing SN
Main motor
Paper feed motor
Registration SN
Paper exit SN
Registration motor
Pressure release SOL
Paper delivery motor
Vacuum fan motor
Air knife fan motor
30 rpm
Y
Check
Check
X
 



C238D045.WMF
