DIP SW, LED, VR, TP, AND FUSE TABLES 28 March 2006
C267 4-8 SM
FUSES
MPU
FUSE #
Rated
Current
Voltage Related Devices
FU 1 1 A 24 V DC Ink Pump Motor
FU 2 2 A 5 V DC UC2 PC Controller
PSU
FUSE #
Rated
Current
Voltage Related Devices
FU 700 6.3 A 120/230V AC AC Line
FU 701 6.3 A 24VDC
Paper Transport Motor, Paper Feed Clutch,
Paper Up-Down Motor, Air Knife Fan Motor,
Front/Rear Pressure Release Solenoid,
Vacuum Fan Motor, Ink Pump Motor, Master
Eject Motor, Optional Key Counter, Master
Counter, Paper Counter, Cutter Motor, Clamper
Motor, Scanner Motor
FU 702 6.3 A 24V DC Not used
FU 703 8 A 24V DC Main Motor
FU 704 6.3 A 24V DC Optional Tape Dispenser
