TIMING CHART
SM 6-57 C267
C267 Service
Manual
6.13.3 MASTER FEED
Clamper Motor
Master Eject
Position Sn
Feed Start
Timing Sn
Send Master to Clamper
Wrapping Master on the Drum
Master Feed
Trial
Print
Main Motor
Master Feed Motor
Master Cut
Clamper Open Sn
Clamper Close Sn
Cutter Motor
Cutter HP Switch
Finished Master Eject
C267D912.WMF
