Remote control commands
R&S
®
RTP
2245User Manual 1337.9952.02 ─ 12
TDRT:PULSe:INVout <Channel>
Sets the channel to which the connector of the pulse source is connected via cali-
bration standard or DUT. Only required for differential measurements.
Parameters:
<Channel> C1W1 | C2W1 | C3W1 | C4W1
*RST: C3W1
Usage: Asynchronous command
TDRT:PULSe:INVReference
<Channel>
Sets the channel to which the
connector of the pulse source is connected. Only
required for differential measurements.
Parameters:
<Channel> C1W1 | C2W1 | C3W1 | C4W1
*RST: C4W1
Usage: Asynchronous command
TDRT:SLENgth <ShortLength>
Sets the electrical length of a user-defined short.
The reset value is the electrical length of the short hat is delivered with the pulse
source R&S RTP-B7.
Parameters:
<ShortLength> Range: 0 to 2E-9
Increment: 1E-12
*RST: 26.5E-12
Default unit: s
Usage: Asynchronous command
TDRT:CALibration:SAVE:NAME <Path>
Sets the file name, file format and path of the TDR/TDT calibration file to be saved.
The file format is always .xml.
Parameters:
<Path> String with path and file name with extension .xml
Usage: Asynchronous command
TDRT:CALibration:SAVE[:EXECute]
Saves the TDR/TDT calibration results to the file that is specified with TDRT:
CALibration:SAVE:NAME.
Pulse source and TDR/TDT analysis (options R&S
RTP-B7/K130)
