Remote control commands
R&S
®
RTP
2284User Manual 1337.9952.02 ─ 12
ADVJitter<m>:DCOMposition:JINTerleaved <State>
Displays interleaved histogram values.
Suffix:
<m>
.
1..2
Parameters:
<State> ON | OFF
*RST: OFF
22.22.2.3 Advanced settings
ADVJitter<m>:DCOMposition:MRESplength?................................................................. 2284
ADVJitter<m>:DCOMposition:RLEStimate......................................................................2284
ADVJitter<m>:DCOMposition:POSStep..........................................................................2284
ADVJitter<m>:DCOMposition:RESPlength......................................................................2285
ADVJitter<m>:DCOMposition:ENP.................................................................................2285
ADVJitter<m>:DCOMposition:NHORizontal.................................................................... 2285
ADVJitter<m>:DCOMposition:NVERtical........................................................................ 2286
ADVJitter<m>:DCOMposition:ENOBu............................................................................ 2286
ADVJitter<m>:DCOMposition:MRESplength?
Queries the estimated maximum step length response.
Suffix:
<m>
.
1..2
Return values:
<MaxLength> Range: 1 to 200
Increment: 1
*RST: 20
Default unit: UI
Usage: Query only
ADVJitter<m>:DCOMposition:RLEStimate
Runs an estimate of the step response for the advanced jitter analysis measurements.
Suffix:
<m>
.
1..2
Usage: Event
Asynchronous command
ADVJitter<m>:DCOMposition:POSStep <Position>
Sets the steps position.
Jitter analysis and clock data recovery
