SINUS PENTA
PROGRAMMING GUIDE
122/486
P071 Value of FIN Producing Min. Reference (X-axis)
P071
Range
1000 ÷ 10000
10 kHz ÷ 100 kHz
Default
1000
10 kHz
Level
ADVANCED
Address
671
Function
This parameter selects the value of the frequency input signal for minimum
reference, or better the reference set in C028xP071a
(Master mode) or in
C047xP071a (Slave mode). If motor 2 is active, C071 and C090
will be used instead
of C028 and C047; if motor 3 is active, the values set in C114 and C133 will be used.
P071a Percentage of Speed_Min/Trq_Min Producing Min. Reference (Y-axis related to P071)
P071a
Range
0 ÷ 1000
100.0%
Default
1000
100.0%
Level
ADVANCED
Address
713
Function
This parameter represents the min. speed percentage (or the min. torque percentage
for a torque reference) to be used for the minimum reference set with P071.
P072 Value of FIN Producing Max. Reference (X-axis)
P072
Range
1000 ÷ 10000
10 kHz ÷ 100 kHz
Default
10000
100 kHz
Level
ADVANCED
Address
672
Function
This parameter selects the value of the frequency input signal for maximum
reference,
or better the reference set in C029xP072a (Master mode) or in
C048xP072a (Slave mode). If motor 2 is active, C072 and C091 will be used
instead of C029 and C048; if motor 3 is active, the values set in C115 and C134
will
be used.
P072a Percentage of Speed_Max/Trq_Max Producing Max. Reference (Y-axis related to P072)
P072a
Range
0 ÷ 1000
100.0%
Default
1000
100.0%
Level
ADVANCED
Address
714
Function
This parameter represents the max. speed percentage (or the max. torque
percentage for a torque reference) to be used for the maximum reference set with
P072.
