Santerno Sinus Penta - Page 159

PROGRAMMING GUIDE
SINUS PENTA
159/486
P188 AO2 Analog Output Offset
P188 Range
–9999 ÷ +9999
Depends on the value
selected in P184
-9.999 ÷ 9.999
Default
0
0.000 V
Level
ADVANCED
Address
788
Function
Offset value applied to AO2 analog output.
P189 Filter for AO2 Analog Output
P189
Range
0 ÷ 65000
0.000÷65.000 sec.
Default
0
0.000 sec.
Level
ADVANCED
Address
789
Function
Value of the filter time constant applied to AO2 analog output.
P190 Min. AO2 Output Value with Reference to P186
P190 Range
–100 ÷ +100
–200 ÷ +200
Depends on the value
selected in P184
–10.0 ÷ +10.0 V
–20.0 ÷ +20.0 mA
Default
–100
–10.0 V
Level
ADVANCED
Address
790
Function
Minimum output value obtained when the minimum value of the variable set in
P186 is implemented.
P191 Max. AO2 Output Value with Reference to P187
P191 Range
-100 ÷ +100
–200 ÷ +200
Depends on the value
selected in P184
–10.0 ÷ +10.0 V
–20.0 ÷ +20.0 mA
Default
+100
+10,0 V
Level
ADVANCED
Address
791
Function
Maximum output value obtained when the maximum value of the variable set in
P187 is implemented.
P192 AO3 Analog Output
P192 Range
0 ÷ 7
0: Disabled,
1: ± 10V,
2: 0 ÷ 10V,
3: 0 ÷ 20mA,
4: 4 ÷ 20mA,
5: ABS 0 ÷ 10V,
6: ABS 0 ÷ 20mA,
7: ABS 4 ÷ 20mA.
Default
2
2: 0 ÷ 10V
Level
ADVANCED
Address
792
Function
Selects the operating mode of AO3 analog output.
