Santerno Sinus Penta - Page 339

PROGRAMMING GUIDE
SINUS PENTA
339/486
C170 SLAVE Input
C170 Range
0 ÷ 16
0 ÷ 24 if ES847 or ES870 is fitted
0 → Inactive
1 ÷ 8 → MDI1 ÷ MDI8
9 ÷ 12 → MPL1 ÷ MPL4
13 ÷ 16 → TFL1 ÷ TFL4
17 ÷ 24 → XMDI1 ÷ XMDI8
Default
0
Inactive
Level
ADVANCED
Address
1170
Control
VTC and FOC
Function
When activating the terminal allocated to the Slave Input, the main reference becomes
a torque reference and the speed loop is by-passed.
This function enables the SLAVE operating mode (torque reference
), instead of the
MASTER operating mode (speed reference); the Torque References and the
Ramp
Torques are used (see the INPUTS FOR REFERENCES MENU and the
RAMPS
MENU).
