5. PARAMETERS
5 - 22
No./symbol/
name
Setting
digit
Function
Initial
value
[unit]
Control
mode
P
S
T
PA20
*TDS
Tough drive
setting
Alarms may not be avoided with the tough drive function depending on the situations of the power supply and load
fluctuation.
You can assign MTTR (During tough drive) to the pins CN1-22 to CN1-25, CN1-49, CN1-13, and CN1-14 with [Pr.
PD23] to [Pr. PD26], [Pr. PD28], and [Pr. PD47].
_ _ _ x
For manufacturer setting
0h
_ _ x _
Vibration tough drive selection
0: Disabled
1: Enabled
Selecting "1" enables to suppress vibrations by automatically changing setting
values of [Pr. PB13 Machine resonance suppression filter 1] and [Pr. PB15 Machine
resonance suppression filter 2] in case that the vibration exceed the value of the
oscillation level set in [Pr. PF23].
To output the oscillation detection alarm as a warning, set [Pr. PF24 Vibration tough
drive function selection].
Refer to section 7.3 for details.
0h
_ x _ _
SEMI-F47 function selection
0: Disabled
1: Enabled
Selecting "1" enables to avoid occurring [AL. 10 Undervoltage] using the electrical
energy charged in the capacitor in case that an instantaneous power failure occurs
during operation. In [Pr. PF25 SEMI-F47 function - Instantaneous power failure
detection time], set the time period until the occurrence of [AL. 10.1 Voltage drop in
the control circuit power].
0h
x _ _ _
For manufacturer setting
0h
PA21
*AOP3
Function
selection A-3
_ _ _ x
One-touch tuning function selection
0: Disabled
1: Enabled
When the digit is "0", the one-touch tuning is not available.
1h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
Electronic gear selection
0: Electronic gear ([Pr. PA06] and [Pr. PA07])
1: Number of command input pulses per revolution ([Pr. PA05])
2: J3 electronic gear setting value compatibility mode
(Electronic gear ([Pr. PA06] and [Pr. PA07] × 16))
The electronic gear setting value can be used set with LECSB
□
-S
□
.
0h
PA22
*PCS
Position
control
composition
selection
_ _ _ x
For manufacturer setting
0h
_ _ x _
Super trace control selection
0: Disabled
2: Enabled
0h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
