3. SIGNALS AND WIRING
3 - 22
3.5 Signal (device) explanations
The pin numbers in the connector pin No. column are those in the initial status.
For the I/O interfaces (symbols in I/O division column in the table), refer to section 3.9.2. The symbols in the
control mode field of the table shows the followings.
P: Position control mode
S: Speed control mode
T: Torque control mode
" " and " " of the table shows the followings.
: Usable device by default.
: Usable device by setting the following parameters.
[Pr. PA04], [Pr. PD03] to [Pr. PD26], [Pr. PD28], and [Pr. PD47]
(1) I/O device
(a) Input device
Device
Symbol
Connector
pin No.
Function and application
I/O
division
Control
mode
P
S
T
Forced stop 2
EM2
CN1-42
Turn off EM2 (open between commons) to decelerate the servo motor to a
stop with commands.
Turn EM2 on (short between commons) in the forced stop state to reset
that state.
The following shows the setting of [Pr. PA04].
DI-1
[Pr. PA04]
setting
EM2/EM1
Deceleration method
EM2 or EM1 is off
Alarm occurred
0 _ _ _
EM1
MBR (Electromagnetic
brake interlock) turns
off without the forced
stop deceleration.
MBR (Electromagnetic
brake interlock) turns
off without the forced
stop deceleration.
2 _ _ _
EM2
MBR (Electromagnetic
brake interlock) turns
off after the forced
stop deceleration.
MBR (Electromagnetic
brake interlock) turns
off after the forced
stop deceleration.
EM2 and EM1 are mutually exclusive.
EM2 has the same function as EM1 in the torque control mode.
Forced stop 1
EM1
(CN1-42)
When using EM1, set [Pr. PA04] to "0 _ _ _" to enable EM1.
When EM1 is turned off (open between commons), the base circuit shuts
off, and the dynamic brake operates to decelerate the servo motor to a
stop.
Turn EM1 on (short between commons) in the forced stop state to reset
that state.
DI-1
Servo-on
SON
CN1-15
Turn SON on to power on the base circuit and make the driver ready to
operate. (servo-on status)
Turn it off to shut off the base circuit and coast the servo motor.
Set "_ _ _ 4" in [Pr. PD01] to switch this signal on (keep terminals
connected) automatically in the driver.
DI-1
Reset
RES
CN1-19
Turn on RES for more than 50 ms to reset the alarm.
Some alarms cannot be deactivated by RES (Reset). Refer to chapter 8.
Turning RES on in an alarm-free status shuts off the base circuit. The
base circuit is not shut off when " _ _ 1 _ " is set in [Pr. PD30].
This device is not designed to make a stop. Do not turn it on during
operation.
DI-1
