11. OPTIONS AND PERIPHERAL EQUIPMENT

11 - 17

11.4 Battery (LEC-MR-BAT6V1SET)

POINT

Refer to appendix 2 and 3 for battery transportation and the new EU Battery

Directive.

(1) Purpose of use for LEC-MR-BAT6V1SET

This battery is used to construct an absolute position detection system. Refer to section 12.3 for the

fitting method, etc.

(2) Year and month of manufacture of battery

The year and month of manufacture of LEC-MR-BAT6V1SET have been described to the rating

plate.

Rating plate

2CR17335A WK17

11-04

6V 1650mAh

The year and month of manufacture
