17．Positioning mode (pushing operation)
17.14.3 Detailed explanations of commands
Refer to Chapter 16 for items not described in this chapter.
17.14.4 External I/O signal status (DIO diagnosis)
Refer to Chapter 16 for items not described in this chapter.
(1) Reading the status of input devices
(2) Reading external input pin status
(3) Reading the status of the input device turned on by communication
(4) Reading external output pin status
Same as standard product.
(5) Reading output device status
You can read the on / off status of the output device.
(a) Sending
Send command [1] [2] + data number [8] [0] to [8] [3].
Command
Data number
[1][2]
[8][0]to[8][3]
(b) Replying
The slave returns a double status by input / output.
b31 b1b0
1: On
0: Off
Command of each bit is transmitted to the master station as hexadecimal data.
bit
abbreviation
Data number [8][0]
Data number [8][1]
Data number [8][2]
Data number [8][3]
0
RD
MCD00
1
SA
MCD01
2
ZSP
MCD02
3
TLC
CPO
MCD03
4
VLC
ZP
MCD10
5
INP
POT
MCD11
6
PUS
MCD12
7
WNG
MEND
MCD13
8
ALM
ACD0
9
OP
ACD1
10
MBR
ACD2
11
DB
ACD3
12
ALCD0
PED
PRQ0
13
ALCD1
PRQ1
14
ALCD2
15
BWNG
16
17
ALMWNG
18
BW9F
19
TFBL
MSDH
20
PERR
MSDL
21
SOUT
22
OUT1
23
OUT2
24
OUT3
PT0/PS0
25
CDPS
CAMS
PT1/PS1
26
CLDS
CLTS
PT2/PS2
27
ABSV
CLTSM
PT3/PS3
28
CLTS
PT4/PS4
29
PT5/PS5
30
PT6/PS6
31
MTTR
PT7/PS7
