14. COMMUNICATION FUNCTION
14 - 37
14.5.9 Output signal pin on/off (output signal (DO) forced output)
In the test operation mode, the output signal pins can be turned on/off regardless of the servo status. Using
command [9] [0], disable the external output signals in advance.
(1) Selecting output signal (DO) forced output in the test operation mode
Transmit command + [8] [B] + data No. [0] [0] + data "0004" to select output signal (DO) forced output.
0 0 4
Selection of test operation mode
4: Output signal (DO) forced output
0
(2) External output signal on/off
Transmit the following communication commands.
Command
Data No.
Set data
[9] [2]
[A] [0]
See below.
b31 b1b0
1: On
0: Off
Command of each bit is transmitted to the master station as hexadecimal data.
Bit
CN1 connector pin
Bit
CN1 connector pin
Bit
CN1 connector pin
Bit
CN1 connector pin
0
49
8
14
16
24
1
24
9
17
25
2
23
10
18
26
3
25
11
19
27
4
22
12
20
28
5
48
13
21
29
6
33
14
22
30
7
13
15
23
31
(3) Output signal (DO) forced output
Transmit command [8] [B] + data No. [0] [0] + data to stop output signal (DO) forced output.
Command
Data No.
Transmission
data
Selection of test operation mode
[8] [B]
[0] [0]
0000
Test operation mode cancel
