14. COMMUNICATION FUNCTION
14 - 31
14.5.6 Disabling/enabling I/O devices (DIO)
You can disable inputs regardless of the I/O device status. When inputs are disabled, the input signals
(devices) are recognized as follows. However, EM2 (Forced stop 2), LSP (Forward rotation stroke end), and
LSN (Reverse rotation stroke end) cannot be disabled.
Signal
Status
Input device (DI)
Off
External analog input signal
0 V
Pulse train input
None
(1) Disabling/enabling the input devices (DI), external analog input signals and pulse train inputs except EM2
(Forced stop 2), LSP (Forward rotation stroke end), and LSN (Reverse rotation stroke end).
Transmit the following communication commands.
(a) Disabling
Command
Data No.
Data
[9] [0]
[0] [0]
1EA5
(b) Enabling
Command
Data No.
Data
[9] [0]
[1] [0]
1EA5
(2) Disabling/enabling the output devices (DO)
Transmit the following communication commands.
(a) Disabling
Command
Data No.
Data
[9] [0]
[0] [3]
1EA5
(b) Enabling
Command
Data No.
Data
[9] [0]
[1] [3]
1EA5
