16 - 293
16. POSITIONING MODE
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PD46
*DI12H
Input device
selection 12H
Any input device can be assigned to the CN1-35 pin and the CN1-38 pin.
_ _ x x
Not used with the positioning mode.
00h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for setting values.
When "00" is set, NP/NP2 (Reverse rotation pulse/Manual pulse generator) will be
assigned.
3Bh
PD47
*DO7
Output device
selection 7
Any output device can be assigned to the CN1-13 pin and CN1-14 pin.
_ _ x x
Device selection
Any output device can be assigned to the CN1-13 pin.
Refer to table 7.11 in [Pr. PD23] for setting values.
00h
x x _ _
Device selection
Any output device can be assigned to the CN1-14 pin.
Refer to table 7.11 in [Pr. PD23] for setting values.
00h
16.22.5 Extension setting 2 parameters ([Pr. PE_ _ ])
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PE03
*FCT2
_ _ x x
Do not change this value
。
03h
_ x _ _
For manufacturer setting
0h
x _ _ _
Do not change this value
。
0h
PE04
*FBN
Do not change this value
。
1
PE05
*FBD
Do not change this value
。
1
PE06
BC1
Do not change this value
。
400
[r/min]
PE07
BC2
Do not change this value
。
100
[kpulse]
PE08
DUF
Do not change this value
。
10
[rad/s]
PE10
FCT3
_ _ _ x
For manufacturer setting
0h
_ _ x _
Do not change this value
。
0h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PE34
*FBN2
Do not change this value
。
1
PE35
*FBD2
Do not change this value
。
1
PE41
EOP3
Function
selection E-3
_ _ _ x
Robust filter selection
0: Disabled
1: Enabled
When you select "Enabled" of this digit, the machine resonance suppression filter 5
set in [Pr. PB51] is not available.
0h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
0h
PE44
LMCP
Lost motion
compensation
positive-side
compensation
value
selection
Set the lost motion compensation for when reverse rotation (CW) switches to
forward rotation (CCW) in increments of 0.01% assuming the rated torque as 100%.
Setting range: 0 to 30000
0
[0.01%]
