16. POSITIONING MODE
16.28.2 Input device on/off
POINT
The on/off statuses of all devices in the driver are the status of the data received
at last. Therefore, when there is a device which must be kept on, transmit data
which turns the device on every time.
Each input device can be switched on/off. However, when the device to be switched off is in the external
input signal, also switch off the input signal.
Transmit command [9] [2] + data No. [6] [0] to [6] [3].
Command
Data No.
Setting data
[9] [2]
[6] [0] to [6] [3]
See below.
Bit
Symbol
Data No. [6] [0]
Data No. [6] [1]
Data No. [6] [2]
Data No. [6] [3]
0
SON
MD0
POS00
1
LSP
ABSM
MD1
POS01
2
LSN
ABSR
POS02
3
TL
TCH
POS03
4
TL1
TP0
POS10
5
PC
TP1
POS11
6
RES
OVR
POS12
7
CR
POS13
8
SP1
STAB
POS20
9
SP2
DOG/SIG
POS21
10
SP3
SPD1
POS22
11
ST1/RS2
SPD2
POS23
12
ST2/RS1
SPD3
POSP
13
CMX1
SPD4
POSN
14
CMX2
STRB
15
LOP
16
MSD
LPS
17
PI1
RT
18
EM2/EM1
PI2
RTCDP
19
PI3
20
STAB2
CAMC
OV0
21
CI0
OV1
22
CI1
OV2
23
CI2
OV3
24
TSTP
CI3
DI0
25
CLTC
DI1
26
CPCD
DI2
27
CDP
DI3
28
CLD
DI4
29
MECR
DI5
30
DI6
31
DI7
b31 b1b0
1: On
0: Off
Command of each bit is transmitted to the master station as hexadecimal data.
