16.7.7 Dog type rear end reference home position return
This home position return method depends on the timing of reading DOG
(Proximity dog) that has detected the rear end of a proximity dog. Therefore,
when a home position return is performed at a creep speed of 100 r/min, the
home position has an error of 6400 pulses (for HG series servo motor). The
higher the creep speed, the greater the error of the home position.
Deceleration starts at the front end of a proximity dog. After the rear end is passed, the position is shifted by
the travel distance after proximity dog and the home position shift distance. The position after the shifts is
used as the home position. The home position return is available independently of the Z-phase signal.
Changing the creep speed may change the home position.
(1) Device/parameter
Set input devices and parameters as follows.
Home position return mode
selection
MD0 (Operation mode selection 1)
DI0 (Point table No. selection 1) to
DI7 (Point table No. selection 8)
Dog type rear end reference
home position return
_ _ _ 5: Select the dog type (rear end
detection/rear end reference).
Home position return
direction
Refer to section 4.4.1 (2) to select the home
position return direction.
Refer to section 4.4.1 (2) to select the dog
input polarity.
Home position return speed
Set the rotation speed until the dog is
detected.
Set the rotation speed after the dog is
detected.
Home position shift distance
Set this item to shift the home position, which
is specified after the rear end of a proximity
dog is passed.
Travel distance after
proximity dog
Set the travel distance specified after the rear
end of a proximity dog is passed.
Home position return
acceleration/deceleration time
constant
Use the acceleration/deceleration time
constant of point table No. 1.
Home position return position
data
Set the current position at the home position
return completion.
