16. POSITIONING MODE
16.22.2 Gain/filter setting parameters ([Pr. PB_ _ ])
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PB01
FILT
Adaptive
tuning mode
(adaptive
filter II)
_ _ _ x
Filter tuning mode selection
Set the adaptive tuning.
Select the adjustment mode of the machine resonance suppression filter 1. For
details, refer to section 7.1.2 .
0: Disabled
1: Automatic setting
2: Manual setting
0h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
Tuning accuracy selection
0: Standard
1: High accuracy
The frequency is estimated more accurately in the high accuracy mode compared to
the standard mode. However, the tuning sound may be larger in the high accuracy
mode.
For details, refer to section 7.1.2 .
0h
PB02
VRFT
Vibration
suppression
control tuning
mode
(advanced
vibration
suppression
control II)
_ _ _ x
Vibration suppression control 1 tuning mode selection
Select the tuning mode of the vibration suppression control 1. For details, refer to
section 7.1.5.
0: Disabled
1: Automatic setting
2: Manual setting
0h
_ _ x _
Vibration suppression control 2 tuning mode selection
Select the tuning mode of the vibration suppression control 2. To enable the digit,
select "3 inertia mode (_ _ _ 1)" of "Vibration suppression mode selection" in [Pr.
PA24]. For details, refer to section 7.1.5.
0: Disabled
1: Automatic setting
2: Manual setting
0h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
