17 - 36
17．Positioning mode (pushing operation)
17.8.6 Pushing start error
[AL7F.4 Pushing start error] occurs when there is an error in the pushing operation start method,
PERR (Pushing error) turns on, and the dynamic brake stops.
17.8.7 When pushing operation is started independently
When ST1 (start signal) is turned on by specifying a point table No. with "16" or "18" set in the auxiliary
function of point table data, PERR (Pushing error) turns on and [AL7F.4 Pushing start error] occurs. In
this case, the servo motor does not operate.
RES (reset) resets the alarm and turns off PERR (Pushing error). PERR does not turn off with ST1
(start signal).
17.8.8 When the dwell is set immediately before the pushing operation
When the dwell is set immediately before the pushing operation, [AL7F.4 Pushing start error] occurs
after reaching the pushing start position and the dwell time has elapsed, PERR (Pushing error) is
turned on, and the dynamic brake is activated. The servo motor stops.
In this case, set the dwell of the point table data immediately before the pushing operation to “0”.
RES (reset) resets the alarm and turns off PERR (Pushing error). PERR does not turn off with ST1
(start signal).
(1) Point table setting example
a) For positioning operation (absolute value command method) and pushing operation (absolute
value command method)
Point
table No.
Position data /
Pushing limit
position
[10^stm μm]
Servo motor rotation
speed / speed limit
value
[r/min]
Acceleration
time
constant
[ms]
Deceleration
time
constant
[ms]
Dwell
[ms]
Auxiliary
function
M code
Pushing
torque
[0.1%]
1
8.00
3000
100
150
100
1
0(Note1)
0(Note1)
2
12.00
500
0(Note1)
0(Note1)
0(Note1)
16
0(Note1)
500
3
0
2000
100
300
0
0
15
0(Note1)
Note1: The set value of the point table becomes invalid. Refer to section 6.1.3 of this specification
for details.
