9. OUTLINE DRAWINGS
9 - 2
9. OUTLINE DRAWINGS
9.1 Driver
(1) LECSB2-T5/LECSB2-T7
[Unit: mm]
156
6
6
40
6
6 135
4
CNP2
CNP1
CNP3
PE
168
161
Approx. 80
Approx. 21
Approx. 38.5
Approx. 69.3
With
MR-BAT6V1SET
Lock knob
φ6 mounting hole
Mass: 0.8 [kg]
L2
P3
L11
L21
P4
L3
L1
C
D
P+
PE
Terminal
CNP1
CNP2
V
W
U
CNP3
Screw size: M4
Tightening torque: 1.2 [N•m]
N-
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
6
Approx. 6
Approx. 168
Approx. 40
156 ± 0.5
Mounting hole process drawing
Approx. 6
2-M5 screw
LEC-
