5. PARAMETERS
5 - 6
5.1.3 Extension setting parameters ([Pr. PC_ _ ])
No.
Symbol
Name
Initial
value
Unit
Operation
mode
Control
mode
Standard
P
S
T
PC01
STA
Acceleration time constant
0
[ms]
PC02
STB
Deceleration time constant
0
[ms]
PC03
STC
S-pattern acceleration/deceleration time constant
0
[ms]
PC04
TQC
Torque command time constant/thrust command time
constant
0
[ms]
PC05
SC1
Internal speed command 1
100
[r/min]
Internal speed limit 1
PC06
SC2
Internal speed command 2
500
[r/min]
Internal speed limit 2
PC07
SC3
Internal speed command 3
1000
[r/min]
Internal speed limit 3
PC08
SC4
Internal speed command 4
200
[r/min]
Internal speed limit 4
PC09
SC5
Internal speed command 5
300
[r/min]
Internal speed limit 5
PC10
SC6
Internal speed command 6
500
[r/min]
Internal speed limit 6
PC11
SC7
Internal speed command 7
800
[r/min]
Internal speed limit 7
PC12
VCM
Analog speed command - Maximum speed
0
[r/min]
Analog speed limit - Maximum speed
PC13
TLC
Analog torque/thrust command maximum output
100.0
[%]
PC14
MOD1
Analog monitor 1 output
0000h
PC15
MOD2
Analog monitor 2 output
0001h
PC16
MBR
Electromagnetic brake sequence output
0
[ms]
PC17
ZSP
Zero speed
50
[r/min]
PC18
*BPS
Alarm history clear
0000h
PC19
*ENRS
Encoder output pulse selection
0000h
PC20
*SNO
Station No. setting
0
[station]
PC21
*SOP
RS-422 communication function selection
0000h
PC22
*COP1
Function selection C-1
0000h
PC23
*COP2
Function selection C-2
0000h
PC24
*COP3
Function selection C-3
0000h
PC25
For manufacturer setting
0000h
PC26
*COP5
Function selection C-5
0000h
PC27
*COP6
Function selection C-6
0000h
PC28
*COP7
Function selection C-7
0000h
PC29
For manufacturer setting
0000h
PC30
STA2
Acceleration time constant 2
0
[ms]
PC31
STB2
Deceleration time constant 2
0
[ms]
PC32
CMX2
Command input pulse multiplication numerator 2
1
PC33
CMX3
Command input pulse multiplication numerator 3
1
PC34
CMX4
Command input pulse multiplication numerator 4
1
PC35
TL2
Internal torque limit 2/internal thrust limit 2
100.0
[%]
PC36
*DMD
Status display selection
0000h
PC37
VCO
Analog speed command offset
0
[mV]
Analog speed limit offset
