16 - 241
16. POSITIONING MODE
16.21.3 Extension setting parameters ([Pr. PC_ _ ])
POINT
To enable the following parameters in a positioning mode, cycle the power after
setting.
[Pr. PC03 S-pattern acceleration/deceleration time constant]
The following parameter cannot be used in the positioning mode.
[Pr. PC04 Torque command time constant/thrust command time constant]
[Pr. PC08 Internal speed command 4/internal speed limit 4]
[Pr. PC09 Internal speed command 5/internal speed limit 5]
[Pr. PC10 Internal speed command 6/internal speed limit 6]
[Pr. PC11 Internal speed command 7/internal speed limit 7]
[Pr. PC12 Analog speed command - Maximum speed/Analog speed limit -
Maximum speed]
[Pr. PC13 Analog torque/thrust command maximum output]
[Pr. PC23 Function selection C-2]
[Pr. PC32 Command input pulse multiplication numerator 2]
[Pr. PC33 Command input pulse multiplication numerator 3]
[Pr. PC34 Command input pulse multiplication numerator 4]
No.
Symbol
Name
Initial
value
Unit
Operation
mode
Control
mode
Standard
CP
CL
PS
PC01
STA
JOG operation acceleration time constant
0
[ms]
Acceleration time constant 1
PC02
STB
JOG operation deceleration time constant
0
[ms]
Deceleration time constant 1
PC03
*STC
S-pattern acceleration/deceleration time constant
0
[ms]
PC04
TQC
Torque command time constant/thrust command time
constant
0
PC05
SC1
Automatic operation speed 1
100
[r/min]
PC06
SC2
Automatic operation speed 2
500
[r/min]
PC07
SC3
Manual operation speed 1
1000
[r/min]
PC08
SC4
Internal speed command 4
200
[r/min]
Internal speed limit 4
PC09
SC5
Internal speed command 5
300
[r/min]
Internal speed limit 5
PC10
SC6
Internal speed command 6
500
[r/min]
Internal speed limit 6
PC11
SC7
Internal speed command 7
800
[r/min]
Internal speed limit 7
PC12
VCM
Analog speed command - Maximum speed
0
[r/min]
Analog speed limit - Maximum speed
PC13
TLC
Analog torque/thrust command maximum output
100.0
[%]
