SMC Networks LECSB2-T Series User Manual

16 - 242
16. POSITIONING MODE
No.
Symbol
Name
Initial
value
Unit
Operation
mode
Control
mode
Standard
CP
CL
PS
PC14
MOD1
Analog monitor 1 output
0000h
PC15
MOD2
Analog monitor 2 output
0001h
PC16
MBR
Electromagnetic brake sequence output
0
[ms]
PC17
ZSP
Zero speed
50
[r/min]
PC18
*BPS
Alarm history clear
0000h
PC19
*ENRS
Encoder output pulse selection
0000h
PC20
*SNO
Station No. setting
0
[station]
PC21
*SOP
RS-422 communication function selection
0000h
PC22
*COP1
Function selection C-1
0000h
PC23
*COP2
Function selection C-2
0000h
PC24
*COP3
Function selection C-3
0000h
PC25
For manufacturer setting
0000h
PC26
*COP5
Function selection C-5
0000h
PC27
*COP6
Function selection C-6
0000h
PC28
*COP7
Function selection C-7
0000h
PC29
For manufacturer setting
0000h
PC30
STA2
Home position return acceleration time constant
0
[ms]
Acceleration time constant 2
PC31
STB2
Home position return deceleration time constant
0
[ms]
Deceleration time constant 2
PC32
CMX2
Command input pulse multiplication numerator 2
1
PC33
CMX3
Command input pulse multiplication numerator 3
1
PC34
CMX4
Command input pulse multiplication numerator 4
1
PC35
TL2
Internal torque limit 2/internal thrust limit 2
100.0
[%]
PC36
*DMD
Status display selection
0000h
PC37
VCO
Analog override offset
0
[mV]
PC38
TPO
Analog torque limit offset
0
[mV]
PC39
MO1
Analog monitor 1 offset
0
[mV]
PC40
MO2
Analog monitor 2 offset
0
[mV]
PC41
For manufacturer setting
0
PC42
0
PC43
ERZ
Error excessive alarm detection level
0
[rev]
PC44
*COP9
Function selection C-9
0000h
PC45
*COPA
Function selection C-A
0000h
PC46
For manufacturer setting
0
PC47
0
PC48
0
PC49
0
PC50
0000h
PC51
RSBR
Forced stop deceleration time constant
100
[ms]
PC52
For manufacturer setting
0
PC53
0
PC54
RSUP1
Vertical axis freefall prevention compensation amount
0
[0.0001rev]
PC55
For manufacturer setting
0
PC56
100
PC57
0000h
PC58
0
PC59
0000h
PC60
*COPD
Function selection C-D
0000h
