16. POSITIONING MODE
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PD42
*DIA4
Input signal
automatic on
selection 4
_ x _ _
(HEX)
_ _ _ x (BIN): DI0 (point table No/Program No./next station No. selection 1)
0h
0: Disabled (Use for an external input signal.)
1: Enabled (automatic on)
_ _ x _ (BIN): DI1 (point table No/program No./next station No. selection 2)
0: Disabled (Use for an external input signal.)
1: Enabled (automatic on)
_ x _ _ (BIN): DI2 (point table No/program No./next station No. selection 3)
0: Disabled (Use for an external input signal.)
1: Enabled (automatic on)
x _ _ _ (BIN): DI3 (point table No/program No./next station No. selection 4)
0: Disabled (Use for an external input signal.)
1: Enabled (automatic on)
x _ _ _
(HEX)
_ _ _ x (BIN): DI4 (point table No/Program No./next station No. selection 5)
0h
0: Disabled (Use for an external input signal.)
1: Enabled (automatic on)
_ _ x _ (BIN): DI5 (point table No/program No./next station No. selection 6)
0: Disabled (Use for an external input signal.)
1: Enabled (automatic on)
_ x _ _ (BIN): DI6 (point table No/program No./next station No. selection 7)
0: Disabled (Use for an external input signal.)
1: Enabled (automatic on)
x _ _ _ (BIN): DI7 (point table No/program No./next station No. selection 8)
0: Disabled (Use for an external input signal.)
1: Enabled (automatic on)
Convert the setting value into hexadecimal as follows.
PD44
*DI11H
Input device
selection 11H
Any input device can be assigned to the CN1-10 pin/CN1-37 pin.
_ _ x x
Not used with the positioning mode.
00h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for setting values.
When "00" is set, PP/PP2 (Forward rotation pulse/Manual pulse generator) will be
assigned.
3Ah
0
Initial value
BIN HEX
Input device
0
0
0
0
0
DI2 (Point table No/Program No./Next station No. selection 3)
DI0 (Point table No/Program No./Next station No. selection 1)
DI1 (Point table No/Program No./Next station No. selection 2)
DI3 (Point table No/Program No./Next station No. selection 4)
0
Initial value
BIN HEX
Input device
0
0
0
0
RTCDP (Second acceleration/deceleration gain selection)
RT (Second acceleration/deceleration selection)
0
Initial value
BIN HEX
Input device
0
0
0
0
DI4 (Point table No/Program No./Next station No. selection 5)
DI5 (Point table No/Program No./Next station No. selection 6)
DI6 (Point table No/Program No./Next station No. selection 7)
DI7 (Point table No/Program No./Next station No. selection 8)
BIN 0: Use for an external input signal.
BIN 1: Automatic on
