5. PARAMETERS
5 - 28
No./symbol/
name
Setting
digit
Function
Initial
value
[unit]
Control
mode
P
S
T
PB14
NHQ1
Notch shape
selection 1
Set the shape of the machine resonance suppression filter 1.
When "Filter tuning mode selection" is set to "Automatic setting (_ _ _ 1)" in [Pr. PB01], this parameter will be
adjusted automatically by adaptive tuning.
When "Filter tuning mode selection" is set to "Manual setting (_ _ _ 2)" in [Pr. PB01], the setting value will be
enabled.
_ _ _ x
For manufacturer setting
0h
_ _ x _
Notch depth selection
0: -40 dB
1: -14 dB
2: -8 dB
3: -4 dB
0h
_ x _ _
Notch width selection
0: α = 2
1: α = 3
2: α = 4
3: α = 5
0h
x _ _ _
For manufacturer setting
0h
PB15
NH2
Machine
resonance
suppression
filter 2
Set the notch frequency of the machine resonance suppression filter 2.
To enable the setting value, set "Machine resonance suppression filter 2 selection"
to "Enabled (_ _ _ 1)" in [Pr. PB16].
Setting range: 10 to 4500
4500
[Hz]
PB16
NHQ2
Notch shape
selection 2
Set the shape of the machine resonance suppression filter 2.
_ _ _ x
Machine resonance suppression filter 2 selection
0: Disabled
1: Enabled
0h
_ _ x _
Notch depth selection
0: -40 dB
1: -14 dB
2: -8 dB
3: -4 dB
0h
_ x _ _
Notch width selection
0: α = 2
1: α = 3
2: α = 4
3: α = 5
0h
x _ _ _
For manufacturer setting
0h
