1. FUNCTIONS AND CONFIGURATION
1 - 4
Note 1.
The built-in regenerative resistor is not provided for LECSB2-T5.
2.
For 1-phase 200 V AC to 240 V AC, connect the power supply to L1 and L3. Leave L2 open. For the power supply
specifications, refer to section 1.3.
3.
Drivers LECSB2-T9 or more have a cooling fan.
4.
The LECSB2-T
□
driver has P3 and P4 in the upstream of the inrush current suppression circuit. They are different from P1
and P2 of the LECSB
□
-S
□
drivers.
5.
CN2L cannot be used. Connect the encoder cable to CN2.
6.
short P3 and P4.
