7. SPECIAL ADJUSTMENT FUNCTIONS

7 - 7

(2) Parameter

Select how to set the filter tuning in [Pr. PB01 Adaptive tuning mode (adaptive filter II)].

[Pr. PB01]

Filter tuning mode selection

0 0

Setting

value

Filter tuning mode selection

Disabled

Automatic setting

Manual setting

PB13/PB14

Automatically set parameter

Tuning accuracy selection (Note)

0: Standard

1: High accuracy
