1. FUNCTIONS AND CONFIGURATION
1 - 16
Note 1.
The power factor improving AC reactor can also be used.
2.
For 1-phase 200 V AC to 240 V AC, connect the power supply to L1 and L3. Leave L2 open. For the power supply
specifications, refer to section 1.3.
3.
Depending on the main circuit voltage and operation pattern, bus voltage decreases, and that may cause the forced stop
deceleration to shift to the dynamic brake deceleration. When dynamic brake deceleration is not required, slow the time to
turn off the magnetic contactor.
4.
CN2L can not be used. Connect the encoder cable to CN2.
5.
Always connect between P+ and D terminals. When using the regenerative option, refer to section 11.2.
