9. OUTLINE DRAWINGS
9 - 4
(3) LECSB2-T9
[Unit: mm]
156
6
4212
6
60
6
12 Approx. 80
Cooling fan
air intake
Exhaust
185
Approx. 38.5
6
Approx. 21
Approx.
69.3
168
161
φ6 mounting hole
Lock knob
With
MR-BAT6V1SET
Mass: 1.4 [kg]
L2
P3
L11
L21
P4
L3
L1
C
D
P+
PE
Terminal
CNP1
CNP2
V
W
U
CNP3
Screw size: M4
Tightening torque: 1.2 [N•m]
N-
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
156 ± 0.5
Mounting hole process drawing
Approx. 6
Approx. 6
Approx. 168
42 ± 0.3
3-M5 screw
Approx. 6Approx. 12
Approx. 60
LEC-
