13. USING STO FUNCTION

13 - 12

(b) When outputting two STO states by using one TOFB

If polarity of diode is

reversed, servo amplifier

will malfunction.

TOFCOM

Servo amplifier

TOFB2

LoadTOFB1

(Note)

24 V DC ± 10%

300 mA

Note.

If the voltage drop (maximum of 5.2 V) interferes with the relay operation, apply high

voltage (maximum of 26.4 V) from external source.

Driver

driver
