Operational specifications
Positioning by specifying the station position (Note 7)
The maximum number of divisions: 255
Selects the rotation speed and acceleration/deceleration time constant by a contact input.
Rotation direction specifying indexer/shortest rotating indexer
Selects the override multiplying factor by a contact input.
Set with parameter or external analog input (0 V DC to +10 V DC/maximum torque)
Each
positioning
operation
Point table No. input method/position data input method
Operates each positioning based on position command and speed command.
Automatic
continuous
positioning
operation
Varying-speed operation (2 to 255 speeds)/automatic continuous positioning operation (2 to 255 points)/
automatic continuous operation to a point table selected at startup/
automatic continuous operation to the point table No. 1
Depends on settings of program language.
Rotation
direction
specifying
indexer
Positions to the specified station. Rotation direction settable
Shortest
rotating indexer
Positions to the specified station. Rotates in the shorter direction from the current position.
Executes a contact input or an inching operation with the RS-422/RS-485 communication function based on
speed command set with parameters.
Manual pulse
generator
operation
Manual feeding is executed with a manual pulse generator.
Command pulse multiplication: select from ×1, ×10, and ×100 with a parameter.
Decelerates to a stop regardless of the station.
Rotates in a direction specified by the rotation direction decision when the start signal turns on.
Positions to the nearest station where the servo motor can decelerate to a stop when the start signal turns off.
Home position return mode
Returns to home position upon Z-phase pulse after passing through the proximity dog.
home position address settable/home position shift amount settable/home position return direction selectable/
automatic retract on dog back to home position/automatic stroke retract function
Returns to home position upon the encoder pulse count after touching the proximity dog.
Home position return direction selectable/home position shift amount settable/home position address settable/
automatic retract on dog back to home position/automatic stroke retract function
Returns to home position without dog.
Sets any position as a home position using manual operation, etc./home position address settable
Returns to home position upon hitting the stroke end.
Home position return direction selectable/home position address settable
Home position ignorance
(servo-on position as
home position)
Sets a home position where SON (Servo-on) signal turns on.
Home position address settable
Dog type rear end
reference
Returns to home position based on the rear end of the proximity dog.
Home position return direction selectable/home position shift amount settable/home position address settable/
automatic retract on dog back to home position/automatic stroke retract function
Count type front end
reference
Returns to home position based on the front end of the proximity dog.
Home position return direction selectable/home position shift amount settable/home position address settable/
automatic retract on dog back to home position/automatic stroke retract function
Returns to home position upon the first Z-phase pulse based on the front end of the proximity dog.
Home position return direction selectable/home position shift amount settable/home position address settable/
automatic retract on dog back to home position/automatic stroke retract function
Dog type last Z-phase
reference (Note 4)
Returns to home position upon the Z-phase pulse right before the proximity dog based on the front end of the
proximity dog.
Home position return direction selectable/home position shift amount settable/home position address settable/
automatic retract on dog back to home position/automatic stroke retract function
Dog type front end
reference
Returns to home position to the front end of the dog based on the front end of the proximity dog.
Home position return direction selectable/home position shift amount settable/home position address settable/
automatic retract on dog back to home position/automatic stroke retract function
Dogless Z-phase
reference (Note 4)
Returns to home position to the Z-phase pulse with respect to the first Z-phase pulse.
Home position return direction selectable/home position shift amount settable/home position address settable
Torque limit changing dog
type
Returns to home position upon Z-phase pulse after an external limit is detected.
Home position return direction selectable/home position shift amount settable/home position address settable
Torque limit automatic changing function
Torque limit changing data
set type
Returns to home position without external limits.
Sets any position as home position/home position address settable/torque limit automatic changing function
Automatic positioning to home
position function (Note 2)
High-speed automatic positioning to a defined home position
