16. POSITIONING MODE

(5) Forced stop of the servo motor software

Click "Forced Stop" (f) to make an instantaneous stop. When "Forced Stop" is enabled, the servo motor

does not drive even if "Operation Start" is clicked. Click "Forced Stop" again to enable "Operation Start"

to be clicked.

(6) Switch to the normal operation mode

Before switching from the test operation mode to the normal operation mode, turn off the driver.
