16 - 114
16. POSITIONING MODE
(4) Timing chart
ON
OFF
RD (Ready)
ON
OFF
ALM (Malfunction)
ON
OFF
MEND (Travel completion)
CPO (Rough match)
ON
OFF
ON
OFF
SON (Servo-on)
Servo motor
speed
ON
OFF
Forward rotation
0 r/min
Reverse rotation
ON
OFF
ON
OFF
80 ms
Forward rotation JOG
Reverse rotation JOG
ST1 (Forward rotation start)
ST2 (Reverse rotation start)
MD0
(Operation mode selection 1)
