16. POSITIONING MODE
(3) Position data unit
The display unit is expressed in the unit set in [Pr. PT26], and the feed length multiplication is expressed
in the unit set in [Pr. PT03].
When the unit is set in degrees, the roll feed display function is disabled.
Refer to section 4.2.2 for details.
(4) Operation method
Only the status display of the current position and command position changes. The operation method is
the same as each operation mode.
Operation mode
Detailed explanation
Automatic operation
Automatic operation using the point table
Section 4.2.2
Manual operation
JOG operation
Section 4.3.1
Manual pulse generator operation
Section 4.3.2
Home position return mode
Section 4.4
