(5) Verifying point table data (e)
Click "Verify" to verify all the data displayed and data of the driver.
(6) Detailed setting of point table data (f)
Click "Detailed Setting" to change position data range and unit in the point table window. Refer to
section 4.6.2 for details.
(7) Single-step feed (g)
Click "Single-step Feed" to perform the single-step feed test operation. Refer to section 3.1.9 or 3.2.9 for
details.
(8) Copy and paste of point table data (h)
Click "Copy" to copy the selected point table data. Click "Paste" to paste the copied point table data.
(9) Inserting point table data (i)
Click "Insert" to insert a block to the previous row from the selected point table No. The selected point
table No. and lower rows will be shifted down one by one.
(10) Deleting point table data (j)
Click "Delete" to delete all the data of the point table No. selected. The lower rows of the selected point
table No. will be shifted up one by one.
(11) Changing point table data (k)
After selecting the data to be changed, enter a new value, and click "Enter". You can change the
displayed range and unit with "(6) Detailed setting of point table data" of this section.
(12) Reading point table data (l)
Click "Open" to read the point table data.
(13) Saving point table data (m)
Click "Save As" to save the point table data.
(14) Updating project (n)
Click "Update Project" to update the point table data to a project.
