16 - 176
16. POSITIONING MODE
(4) Timing chart
ON
OFF
RD (Ready)
ON
OFF
ALM (Malfunction)
ON
OFF
Servo motor speed
SON (Servo-on)
Forward rotation
0 r/min
Reverse rotation
PED
(Position end)
MD0
(Operation mode selection 1)
ON
OFF
ON
OFF
ON
OFF
ST1 (Forward rotation start)
ST2 (Reverse rotation start)
Forward rotation JOG
ON
OFF
Reverse rotation JOG
80 ms
