16. POSITIONING MODE
The following timing chart shows that an operation is performed at a stop of the station No. 0 when
servo-on.
Note 1.
When the rest of command travel distance is other than "0", ST1 (Forward rotation start) will not be accepted. Refer to section
6.4.5 (1).
2.
RT (Second acceleration/deceleration selection) will not be accepted during operation. Selection of the servo motor speed and
acceleration/deceleration time constants will be enabled by on-edge of ST1 (Forward rotation start). However, when the rest of
command travel distance is other than "0", turning on ST1 (Forward rotation start) will not be enabled.
3.
Counting will start when the rest of command travel distance becomes "0".
4.
When MEND (Travel completion) is off, the station position outputs will be "0" (all off).
2
1
0
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
7
6
5
4
3
Power supply
ON
OFF
ON
OFF
ON
OFF
ALM (Malfunction)
MEND (Travel completion)
PS0 (Station output 1) to
PS7 (Station output 8)
(Note 5)
DI0 (Next station No. selection 1) to
DI7 (Next station No. selection 8)
Servo motor speed
Forward rotation
0 r/min
Reverse rotation
ON
OFF
ST1 (Forward rotation start)
ON
OFF
SIG (External limit/
Rotation direction decision/
Automatic speed selection)
ON
OFF
RT (Second acceleration/
deceleration selection)
ON
OFF
MD0
(Operation mode selection 1)
ON
OFF
MD1
(Operation mode selection 2)
Torque limit
Ignored
(Note 1)
5 ms or
longer
[Pr. PC30]
setting time
Torque limit value of
[Pr. PA11] and [Pr. PA12]
Torque limit value of
[Pr. PA11] and [Pr. PA12]
Torque limit value of
[Pr. PC35]
Torque limit value of
[Pr. PC35]
Torque limit value of
[Pr. PC35]
Torque limit value of
[Pr. PA11] and [Pr. PA12]
Ignored
(Note 2)
Station position
No. 3
5 ms or longer
All off (Note 4) All off (Note 4) All off (Note 4)
Station
output 1
Number of stations: 8
5 ms or
longer
5 ms or
longer
[Pr. PC31]
setting time
[Pr. PT39] setting time (Note 3)
Station position
No. 1
Automatic operation speed 1
Next station No. 3
Automatic operation speed 1
[Pr. PC01]
setting time
Station position
No. 1
Next station No. 1
Next station No. 1
Station output 1 Station output 3
[Pr. PC02]
setting time
Automatic operation
speed 1
