16. POSITIONING MODE
(3) Operation
Select a target station No. using 8-bit devices of the DI0 (Next station No. selection 1) to DI7 (Next
station No. selection 8) for positioning.
Device (Note 1)
Selection contents
DI7
DI6
DI5
DI4
DI3
DI2
DI1
DI0
0
0
0
0
0
0
0
0
Next station No. 0
0
0
0
0
0
0
0
1
Next station No. 1
0
0
0
0
0
0
1
0
Next station No. 2
0
0
0
0
0
0
1
1
Next station No. 3
1
1
1
1
1
1
1
0
Next station No. 254
1
1
1
1
1
1
1
1
Setting inhibited
(Note 2)
Note 1.
0: Off
1: On
2.
[AL. 97.2 Next station position warning] will occur.
