16. POSITIONING MODE
No.
Symbol
Name
Initial
value
Unit
Operation
mode
Control
mode
Standard
CP
CL
PS
PE21
For manufacturer setting
0000h
PE22
0000h
PE23
0000h
PE24
0000h
PE25
0000h
PE26
0000h
PE27
0000h
PE28
0000h
PE29
0000h
PE30
0000h
PE31
0000h
PE32
0000h
PE33
0000h
PE34
*FBN2
Fully closed loop control - Feedback pulse electronic gear 2
- Numerator
1
PE35
*FBD2
Fully closed loop control - Feedback pulse electronic gear 2
- Denominator
1
PE36
For manufacturer setting
0.0
PE37
0.00
PE38
0.00
PE39
20
PE40
0000h
PE41
EOP3
Function selection E-3
0000h
PE42
For manufacturer setting
0
PE43
0.0
PE44
LMCP
Lost motion compensation positive-side compensation
value selection
0
[0.01%]
PE45
LMCN
Lost motion compensation negative-side compensation
value selection
0
[0.01%]
PE46
LMFLT
Lost motion filter setting
0
[0.1 ms]
PE47
TOF
Torque offset
0
[0.01%]
PE48
*LMOP
Lost motion compensation function selection
0000h
PE49
LMCD
Lost motion compensation timing
0
[0.1 ms]
PE50
LMCT
Lost motion compensation non-sensitive band
0
[pulse]/
[kpulse]
PE51
For manufacturer setting
0000h
PE52
0000h
PE53
0000h
PE54
0000h
PE55
0000h
PE56
0000h
PE57
0000h
PE58
0000h
PE59
0000h
PE60
0000h
PE61
0.00
PE62
0.00
PE63
0.00
PE64
0.00
