SMC Networks LECSB2-T Series User Manual

16 - 264
16. POSITIONING MODE
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PB19
VRF11
Vibration
suppression
control 1 -
Vibration
frequency
Set the vibration frequency for vibration suppression control 1 to suppress low-
frequency machine vibration.
When "Vibration suppression control 1 tuning mode selection" is set to "Automatic
setting (_ _ _ 1)" in [Pr. PB02], this parameter will be set automatically. When
"Manual setting (_ _ _ 2)" is selected, the setting written to the parameter is used.
For details, refer to section 7.1.5.
Setting range: 0.1 to 300.0
100.0
[Hz]
PB20
VRF12
Vibration
suppression
control 1 -
Resonance
frequency
Set the resonance frequency for vibration suppression control 1 to suppress low-
frequency machine vibration.
When "Vibration suppression control 1 tuning mode selection" is set to "Automatic
setting (_ _ _ 1)" in [Pr. PB02], this parameter will be set automatically. When
"Manual setting (_ _ _ 2)" is selected, the setting written to the parameter is used.
For details, refer to section 7.1.5.
Setting range: 0.1 to 300.0
100.0
[Hz]
PB21
VRF13
Vibration
suppression
control 1 -
Vibration
frequency
damping
Set a damping of the vibration frequency for vibration suppression control 1 to
suppress low-frequency machine vibration.
When "Vibration suppression control 1 tuning mode selection" is set to "Automatic
setting (_ _ _ 1)" in [Pr. PB02], this parameter will be set automatically. When
"Manual setting (_ _ _ 2)" is selected, the setting written to the parameter is used.
For details, refer to section 7.1.5.
Setting range: 0.00 to 0.30
0.00
PB22
VRF14
Vibration
suppression
control 1 -
Resonance
frequency
damping
Set a damping of the resonance frequency for vibration suppression control 1 to
suppress low-frequency machine vibration.
When "Vibration suppression control 1 tuning mode selection" is set to "Automatic
setting (_ _ _ 1)" in [Pr. PB02], this parameter will be set automatically. When
"Manual setting (_ _ _ 2)" is selected, the setting written to the parameter is used.
For details, refer to section 7.1.5.
Setting range: 0.00 to 0.30
0.00
PB23
VFBF
Low-pass
filter selection
_ _ _ x
Shaft resonance suppression filter selection
Select the shaft resonance suppression filter.
0: Automatic setting
1: Manual setting
2: Disabled
When you select "Enabled (_ _ _ 1)" of "Machine resonance suppression filter 4
selection" in [Pr. PB49], the shaft resonance suppression filter is not available.
0h
_ _ x _
Low-pass filter selection
Select the low-pass filter.
0: Automatic setting
1: Manual setting
2: Disabled
0h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PB24
*MVS
Slight
vibration
suppression
control
_ _ _ x
Slight vibration suppression control selection
Select the slight vibration suppression control.
0: Disabled
1: Enabled
To enable the slight vibration suppression control, select "Manual mode (_ _ _ 3)" of
"Gain adjustment mode selection" in [Pr. PA08].
0h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
0h
